Intelligent solutions for paper-to-CAD

Pre­ci­sion. Sim­plic­i­ty. Control.

GTXRaster CAD sim­pli­fies the cus­tomiza­tion of paper-based files by pro­vid­ing seam­less access to raster draw­ings for edit­ing or con­ver­sion to vec­tor-based .dwg for­mat from Bric­sCAD®, Auto­CAD® or ZWCAD®. You can mod­i­fy geom­e­try with­out redraw­ing it, or use auto­mat­ed raster-to-vec­tor conversion.

GTXRaster CAD can help your orga­ni­za­tion future-proof its engi­neer­ing archive. It elim­i­nates man­u­al redraw­ing or trac­ing errors, mis­align­ments and imper­fec­tions to ensure you have a stream­lined, stress-free workflow.

Eas­i­ly improve your old raster draw­ings with smart tools such as auto­mat­ic and semi-auto­mat­ic clean­ing, straight­en­ing and stain removal.

The built-in Intel­li­gent Object Pick­ing (IOP) meth­ods allow you to select spe­cif­ic raster objects such as lines, arcs and cir­cles to adjust, enabling intu­itive changes such as mov­ing, trans­form­ing, dupli­cat­ing or delet­ing. Merge raster and vec­tor objects effortlessly.

Need ful­ly vec­tor­ized draw­ings? The raster to vec­tor con­ver­sion fea­ture allows you to con­vert raster geom­e­try to CAD enti­ties along with text recog­ni­tion. Your old draw­ing becomes a valu­able dig­i­tal asset.
