CAD­di­rekt VVS allows you to cre­ate draw­ings for var­i­ous types of pip­ing, ven­ti­la­tion, heat­ing, cool­ing, gas and sprin­kler sys­tems. Whether it’s instal­la­tion draw­ings or schemat­ics, CAD­di­rekt VVS is designed to meet the needs of the HVAC indus­try. The tool is devel­oped by plumb­ing experts for plumb­ing experts, ensur­ing effi­cient and user-friend­ly design.

• The tool­bars are struc­tured accord­ing to the design work stages. Ven­ti­la­tion, Pip­ing and Sched­ule have dif­fer­ent tools to give you a nat­ur­al workflow.
• The man­u­al has two parts, descrip­tions and exer­cis­es. The exer­cise part is grouped by plumb­ing sys­tem and it also con­tains a long sec­tion with com­pre­hen­sive infor­ma­tion about the design flow. The man­u­al is full of tips & tricks to get you start­ed quickly.
• Draw plumb­ing sys­tems with dif­fer­ent col­or codes. This facil­i­tates both the design and the sub­se­quent instal­la­tion. Adjust­ments are made in a clear dia­logue. The instal­la­tion draw­ing and the sched­ule are pre­sent­ed with the same col­or codes.
• Save your set­tings and cus­tomiza­tion and share with your colleagues.
• Auto­mat­ic inven­to­ry man­age­ment. Eas­i­ly switch between Byg­ghan­dling 90, BSAB96 or your own stock struc­ture with just one click.
• Sym­bols accord­ing to Swedish stan­dard BH90, Part 2.
• Cre­ate com­po­nent lists from one or more mod­els, the lists can then be processed in Microsoft Excel.
• CAD­di­rekt VVS is a mod­ern 2D appli­ca­tion. CAD­di­rekt VVS does noth­ing that you do not choose to do your­self and the pro­gram does not set any restric­tions on how your doc­u­ments will look. You should be able to dimen­sion a plumb­ing sys­tem already before to draw correctly.
• The struc­ture of the tools is grouped in a well thought-out way, which makes it easy to fol­low the red thread and thus you get a nat­ur­al workflow.
• You have the option of using the same col­or cod­ing in all three tools, Pipes, Ven­ti­la­tion and Dia­gram. This cre­ates increased clar­i­ty. Tool groups are dock­able to the out­er edges to avoid dia­log win­dows on the draw­ing surface.

CAD­di­rekt VVS Ventilation

• CAD­di­rekt VVS for ven­ti­la­tion is struc­tured accord­ing to the work steps for design.
• CAD­di­rekt VVS for ven­ti­la­tion con­tains units, duct sys­tems with details and controls.

CAD­di­rekt VVS Rör

• CAD­di­rekt VVS Rör for pip­ing is struc­tured accord­ing to the work steps that are suit­able for design.
• CAD­di­rekt VVS Rör for pip­ing con­tains pipe sys­tems and pipe details and controls.

CAD­di­rekt VVS Schema

• Based on around 30 basic flow dia­grams, you can quick­ly devel­op your own solution.
