This pro­gram helps to cre­ate plan and con­struc­tion draw­ings as well as sec­tions and lay­outs. It allows you to draw walls, insert doors and win­dows, cre­ate dimen­sions and descrip­tions, and use objects from libraries of fur­ni­ture and oth­er equip­ment. A unique fea­ture of the pro­gram is the abil­i­ty to cre­ate evac­u­a­tion and safe­ty plans.

With the rental license you have full access to CAD­profi Archi­tec­tur­al. After 12 months, you choose whether to con­tin­ue or end the rental.

Room def­i­n­i­tions
Define and label rooms auto­mat­i­cal­ly with area cal­cu­la­tions. Cus­tomiz­able room descriptions.

Con­struct stairs
Design stairs with the pos­si­bil­i­ty to deter­mine dimen­sions and num­ber of steps. Dif­fer­ent types of stairs includ­ing straight, spi­ral, L‑stairs, U‑stairs, U‑stairs with land­ing, stairs with stor­age, con­crete, shelv­ing stairs, stair­case com­po­nents to draw option­al types of stairs are available.

Con­struct roofs
Insert roof with pos­si­bil­i­ty to cal­cu­late roof pitch, roof angles and its height.

Draw walls
Draw sin­gle and mul­ti-lay­er walls with the pos­si­bil­i­ty to define the mate­r­i­al and thick­ness of each wall lay­er and func­tions to draw walls with insulation.

Join­ery details
Para­met­ric join­ery details Para­met­ric join­ery details (doors, win­dows, garage doors) with auto­mat­ic wall thick­ness detec­tion. Plan, sec­tion and lay­out views are avail­able. For para­met­ric objects, the user can spec­i­fy all dimen­sions and properties.

Dimen­sion­ing
Dimen­sion­ing cus­tomized for con­struc­tion projects. The pro­gram allows the user to change the style and units of mea­sure­ment inde­pen­dent­ly of the units used in the draw­ing (e.g. dimen­sions can be set in cm for a draw­ing made in mm).

Fur­ni­ture library
Fur­ni­ture library Library for inte­ri­or design­ers and land­scap­ers: fur­ni­ture, bath­rooms, elec­tron­ics and appli­ances, appli­ances, plants, vehi­cles, pools and hot tubs, saunas and much more.

Gut­ter­ing sys­tems
An exten­sive library of steel, PVC and rec­tan­gu­lar gut­ter sys­tems as well as down­pipes and con­nec­tion details (hooks, drain fun­nels, bot­toms, bends, tees, internal/​external cor­ners, clamp con­nec­tions, spouts, set­tling tanks).

Evac­u­a­tion plans
Draw and edit evac­u­a­tion plans. Library of sym­bols and signs for health and safe­ty, fire pro­tec­tion and gen­er­al information.

Learn more about oth­er key fea­tures of CAD­profi:

• Draw walls along select­ed edge with the abil­i­ty to deter­mine the off­set from indi­cat­ed point or oth­er objects and the abil­i­ty to draw walls along indi­cat­ed info line.
• Easy-to-use con­fig­u­ra­tion allows visu­al selec­tion of win­dows, bal­cony doors, door leaves for inte­ri­or and exte­ri­or doors, garage doors (also indus­tri­al), as well as door and win­dow open­ings, wall open­ings, recess­es and grooves.
• Dynam­i­cal­ly deter­mines the direc­tion of door inser­tion which deter­mines the cor­rect positioning.
• Com­po­nents for Ven­ti­la­tion and chim­ney sys­tems for both sin­gle and dou­ble draft with Schiedel and HOCH sys­tem solu­tions. Con­ve­nient con­fig­u­ra­tion for chim­ney duct design.
• An exten­sive library of chim­neys, includ­ing sin­gle-glazed, cor­ner, triple-glazed, dou­ble-sided, water-jack­et­ed, gas, elec­tric, wood and bio-fireplaces.
• Con­tain­ers and waste receptacles.
• Lev­el sym­bols with auto­mat­ic fill­ing of the coor­di­nates of the points indicated.
• Archi­tec­tur­al sym­bols: holes, ven­ti­la­tion ducts, car­pen­try and wood­en details, slopes, topo­graph­i­cal sym­bols, arrows, gen­er­al sym­bols, etc.
• The work is car­ried out accord­ing to the habits and needs of the user.
• Met­ric and impe­r­i­al units are available.
• Tools for full descrip­tion and project details.
• Auto­mat­ic num­ber­ing of objects.
• A sys­tem for quick search of prod­ucts in the database.
• Access to CAD libraries of many world-renowned manufacturers.
• Pos­si­bil­i­ty to import and add your own sym­bols and objects to the program.
• Auto­mat­ic lay­er man­age­ment and print styles pro­vide the user with prints with pre­de­fined line thick­ness­es, col­ors, etc.
• The abil­i­ty to define ​“favorites” that allow you to work accord­ing to your habits and preferences.
• Smart inser­tion of objects with the pos­si­bil­i­ty to link them to oth­er objects using ​“one-click” technology.
• Intel­li­gent com­mands that allow quick edit­ing of sym­bols and objects direct­ly in the drawing.
• The Quick Edit Com­mand (QED) allows the user to per­form basic edit­ing on sym­bols and objects includ­ing edit­ing attrib­ut­es and descrip­tions, mir­ror­ing, scal­ing, copy­ing, rotat­ing, delet­ing, mov­ing and insert­ing alter­nate views.
• The abil­i­ty to cre­ate option­al dia­grams, flow and func­tion charts and algorithms.
• The abil­i­ty to cre­ate bills of mate­ri­als and spec­i­fi­ca­tions that can either be print­ed or export­ed to many dif­fer­ent for­mats includ­ing pdf, rtf (doc), xls, xml, csv, html and more.
• Cre­ate graph­i­cal lists automatically.
• Online help with many illus­tra­tions and sam­ple videos describ­ing how to use the pro­gram in detail.
• Online update system.

Evac­u­a­tion plans and fire pro­tec­tion instal­la­tions
CAD­profi soft­ware is a com­pre­hen­sive appli­ca­tion that helps with design in both con­struc­tion and indus­try, with a par­tic­u­lar empha­sis on plans and sys­tems that ensure the safe­ty of peo­ple occu­py­ing buildings.

BIM — Abil­i­ty to cre­ate data in BIM tech­nol­o­gy
Build­ing Infor­ma­tion Mod­el­ing (BIM) tech­nol­o­gy is increas­ing­ly used in the con­struc­tion indus­try. Clas­si­fi­ca­tion and man­age­ment of lay­ers based on Open BIM (IFC clas­si­fi­ca­tion) is avail­able in CAD­profi. BIM data is includ­ed in spec­i­fi­ca­tions and can be trans­ferred to pro­grams used dur­ing the invest­ment phase.

In addi­tion, CAD­profi cre­ates data in BIM (includ­ing rfa Revit for­mat) for many man­u­fac­tur­ers. 3D mod­els includ­ed in our pro­gram can also be used in many CAD pro­grams that allow you to import and export files as IFC standard.
