This is an appli­ca­tion used togeth­er with prog­eCAD. CAD­profi helps with the design of all types of elec­tri­cal instal­la­tions in both con­struc­tion and indus­try. The sched­ule cre­ator, after select­ing and plac­ing the appli­ance in the dia­log win­dow, allows you to auto­mat­i­cal­ly gen­er­ate sched­ules for ener­gy dis­tri­b­u­tion. Thanks to this, you can quick­ly pre­pare the project by focus­ing only on the selec­tion of prod­ucts and not on man­u­al drawing.

With the rental license you have full access to CAD­profi Elec­tri­cal. After 12 months you choose whether to con­tin­ue or end the rental.

Stan­dard­ized sym­bols
Com­plete sym­bols for IEC, NFPA, ISO, PN and oth­er libraries that have been pre­pared in accor­dance with both nation­al and inter­na­tion­al stan­dards. Sym­bols can be insert­ed with auto­mat­ic posi­tion­ing, line break­ing, auto­mat­ic num­ber­ing and labeling.

Addressing/​numbering
Fast address­ing of objects and num­ber­ing of elec­tri­cal cir­cuits with auto­mat­ic num­ber­ing control.

Cable routing/​busbars
Design cable routes using con­ve­nient com­mands to draw sequences of cable trays, chan­nels and cable lad­ders with auto­mat­ic inser­tion of appro­pri­ate fit­tings. Cable trays can be drawn auto­mat­i­cal­ly along the spec­i­fied info line. Draw bus­bar instal­la­tions with the pos­si­bil­i­ty to work in 2D or 3D.

Elec­tri­cal sym­bols
Design of floor plans, inser­tion of sock­ets and switch­es, deploy­ment of light­ing fix­tures, design of lin­ear light­ing and pow­er of all types of ener­gy. The pro­gram also has the abil­i­ty to con­fig­ure junc­tion box­es with any con­fig­u­ra­tion of sock­ets and switches.

Switch­es
A rich library of gen­er­al views of mod­u­lar, meter, mul­ti­me­dia, her­met­ic, recessed and sur­face mount­ed switch­boards (dis­trib­u­tors). Recessed, sur­face mount­ed and floor stand­ing sys­tem cab­i­nets with ele­ments of the devel­op­ment sys­tem and addi­tion­al acces­sories: DIN TH35 mount­ing rails.

Enclo­sure selec­tion
Auto­mat­ic gen­er­a­tion of 2D views based on sym­bols used in the project. Auto­mat­ic selec­tion of enclo­sures with the pos­si­bil­i­ty to deter­mine space reserve for pos­si­ble future expan­sion needs.

Mod­u­lar appli­ances
A rich library of gen­er­al views of mod­u­lar devices, includ­ing: pro­tec­tion, con­trol, switch­ing, sig­nal­ing, meter­ing, indus­tri­al, pan­el and switchgear.

Col­lab­o­ra­tion with DIALux
Pos­si­bil­i­ty to import lumi­naires from DIALux. Dur­ing import, all lumi­naires will be replaced with stan­dard CAD­profi blocks and infor­ma­tion about them (name, type) will be tak­en from DIALux and replaced with appro­pri­ate attributes.

Man­u­fac­tur­er libraries
Com­plete libraries of lead­ing man­u­fac­tur­ers (ABB, EATON, Schnei­der Elec­tric, SIEMENS, Hager, Lova­to Elec­tric, ETI, Legrand, Cablofi, DEHN, Noark Elec­tric, Schrack Tech­nik, F&F, RELPOL, Pul­sar and many more).

Learn more about oth­er key fea­tures of CAD­profi Electrical:

• Design pow­er dis­tri­b­u­tion, con­trol and automa­tion instal­la­tions using mul­ti-vari­ant sym­bols that allow option­al con­fig­u­ra­tion of devices.
• Light­ing rails, equip­ment and ded­i­cat­ed light­ing fix­tures, LED strips 12V/24V, Slim, RGB, RGBW, CCT (bi-col­or), RGB + CCT, COB with a set of connectors.
• Pre­de­fined tem­plates for line cir­cuits, dis­tri­b­u­tion cen­ters (switchgear), motor starters and many more.
• Con­struct ICT cab­i­nets with ele­ments of struc­tur­al cables and fiber optic networks.
• Fire alarm con­trol pan­els, con­trol pan­els — overviews and sys­tem solu­tions by AWEX, Bosch, D+H, LST, POLON-ALFA, Satel, Siemens.
• ENER­GA switchgear (dis­trib­u­tors): cables, cable and meter­ing con­nec­tors, cable and meter­ing cab­i­nets, con­nec­tors and street light­ing cab­i­nets, etc.
• Design automa­tion sys­tems — also using PLC con­trollers, includ­ing Siemens LOGO!, SIMAT­IC S7-1200, SIMAT­IC S7-1500.
• Quick­ly and eas­i­ly cre­ate PLC con­troller sym­bols — define block ele­ments, define type, quan­ti­ty and descrip­tion of I/O.
• Block dia­grams, elec­tri­cal schemat­ics and sym­bols for elec­tri­cal equip­ment used in the design of smart build­ings (EIB/KNX instal­la­tion sym­bols, con­trollers, alarm con­trol pan­els, neu­rons, con­vert­ers, input expanders, USB and HDMI exten­ders, PoE switch­es, modems, routers, cam­eras, sen­sors, etc.)
• Design many types of low-volt­age instal­la­tions, includ­ing alarm sys­tems, sur­veil­lance, IP video sur­veil­lance, anten­nas and more.
• Design light­ning pro­tec­tion sys­tems using sys­tem solu­tions from Elko-bis, BUD­NIOK TECH­NI­KA, Paw­bol and Gromtor.
• Design pho­to­volta­ic instal­la­tions using prod­ucts and ready-made pho­to­volta­ic solu­tions from ABB, DEHN, EATON, ETI, Hager, Noark Elec­tric, Lova­to Elec­tric, Schnei­der Elec­tric, SCHRACK Tech­nik and oth­er companies.
• Mate­r­i­al lists/​specifications for the quan­ti­ty of cables and oth­er spec­i­fi­ca­tions that include para­me­ters of elec­tri­cal objects and their con­nec­tion to circuits.
• The draw­ing is done accord­ing to the design­er’s habits and needs.
• Tools for full descrip­tions and project details.
• Auto­mat­ic num­ber­ing of objects.
• A sys­tem for quick search of prod­ucts in the database.
• Access to CAD libraries of many world-renowned manufacturers.
• Pos­si­bil­i­ty to import and add your own sym­bols or objects to the program.
• Auto­mat­ic lay­er man­age­ment and print styles pro­vide the user with prints with pre­de­fined line thick­ness­es, col­ors, etc.
• The abil­i­ty to define ​“favorites” that allow you to work accord­ing to your habits and preferences.
• Smart inser­tion of objects with the pos­si­bil­i­ty to link them to oth­er objects using ​“one-click” technology.
• Intel­li­gent com­mands that allow quick edit­ing of sym­bols and objects direct­ly in the drawing.
• The abil­i­ty to cre­ate option­al dia­grams, flow and func­tion charts and algorithms.
• Abil­i­ty to cre­ate bills of mate­ri­als and spec­i­fi­ca­tions that can either be print­ed or export­ed to mul­ti­ple for­mats includ­ing pdf, rtf (doc), xls, xml, csv, html and more.
• Auto­mat­ic cre­ation of graph­i­cal lists.
• Online help with many illus­tra­tions and sam­ple videos describ­ing how to use the pro­gram in detail.
• Online update system.

Schemat­ic cre­ator
Are you tired of draw­ing sched­ules man­u­al­ly? Do you want to gen­er­ate them auto­mat­i­cal­ly? There is a way! In CAD­profi, after select­ing and plac­ing the appli­ance in the dia­log win­dow, you can auto­mat­i­cal­ly gen­er­ate sched­ules for ener­gy dis­tri­b­u­tion. This way you can quick­ly pre­pare the project focus­ing only on the selec­tion of prod­ucts and not on man­u­al drawing.

BIM — Pos­si­bil­i­ty to cre­ate data in BIM tech­nol­o­gy
The tech­nol­o­gy of BIM (Build­ing Infor­ma­tion Mod­el­ing) is increas­ing­ly used in the con­struc­tion indus­try. Clas­si­fi­ca­tion and man­age­ment of lay­ers based on Open BIM (IFC clas­si­fi­ca­tion) is avail­able in CAD­profi. BIM data is includ­ed in spec­i­fi­ca­tions and can be trans­ferred to pro­grams used dur­ing the invest­ment phase.

In addi­tion, CAD­profi cre­ates data in BIM (includ­ing rfa Revit for­mat) for many man­u­fac­tur­ers. 3D mod­els includ­ed in our pro­gram can also be used in many CAD pro­grams that allow you to import and export files as IFC standard.
