This appli­ca­tion is used togeth­er with prog­eCAD. CAD­profi helps in draw­ing mechan­i­cal and struc­tur­al projects in 2D. The appli­ca­tion con­tains a com­pre­hen­sive set of stan­dard com­po­nents based on nation­al and inter­na­tion­al stan­dards. It is also pos­si­ble to draw and edit tech­ni­cal dia­grams, as well as hydraulic and pneu­mat­ic systems.

With the rental license you have full access to CAD­profi Mechan­i­cal. After 12 months you choose whether to con­tin­ue or end the rental.

Stan­dard com­po­nents
A com­pre­hen­sive set of para­met­ric stan­dard com­po­nents and fas­ten­ers based on nation­al and inter­na­tion­al stan­dards (e.g. ISO, ANSI, ASME, EN, DIN, PN, IS, JIS, GOST), includ­ing bolts, screws, wash­ers, nuts, joints, riv­ets, studs, ori­fices, seams, wedges, pins, bear­ings, grease nip­ples, rings and much more.

Heat exchang­ers
Pro­ce­dures used to cal­cu­late the heat exchang­ers and dif­fer­ent types of tube bun­dles in heat exchangers.

Mark­ings
A set of freely con­fig­urable mark­ings for welds, tol­er­ances, sur­face rough­ness and more. Insert weld views (V‑welds, fil­let welds) with the pos­si­bil­i­ty to define your own dimensions.

Pro­files
Steel and alu­minum pro­files: L‑shapes, C‑shapes, T‑shapes, flat bars, hol­low pro­files, rods, tubes and more. For pro­files it is pos­si­ble to spec­i­fy the mate­r­i­al type (type of steel).

Dynam­ic scal­ing
Dynam­i­cal­ly scale com­po­nents when insert­ing them in draw­ing or when edit­ing projects. This allows to auto­mat­i­cal­ly select the size of the com­po­nents direct­ly in the draw­ing (e.g. select screws with a length adapt­ed to the thick­ness of con­nect­ed details).

Pneu­mat­ic sys­tems
Con­ve­nient design of dia­grams and pneu­mat­ic sys­tems using smart sym­bols, lines and edit­ing functions.

Design­ing appli­ances
Com­po­nents used for design­ing appa­ra­tus, includ­ing flanges and coun­ter­sunk ends, steel pipes and cou­plings (elbows, tees, reduc­ers). It is pos­si­ble to draw pipelines with auto­mat­ic inser­tion of bends and auto­mat­ic con­nec­tion of pipes by using a vari­ety of fittings.

Dif­fer­ent views
All details have dif­fer­ent views cus­tomized to cre­ate dif­fer­ent views (e.g. front views, side views, cross sec­tions, etc.). It is also pos­si­ble to define style and lev­el of detail allow­ing the inser­tion of parts with details, axes, sec­tion mark­ing, etc.

Draw­ing tools
Addi­tion­al draw­ing tools that great­ly facil­i­tate the cre­ation of tech­ni­cal draw­ings (axis, cir­cu­lar axes, cen­ter mark­ings, bisec­tors, etc.). Func­tion to detect all cir­cles in the select­ed block and auto­mat­i­cal­ly insert cir­cle axes or cen­ter marks in them.

Learn more about oth­er key fea­tures of CADprofi:

• Ver­sa­tile edit­ing com­mands that allow for mir­ror­ing of objects, exten­sion of steel pro­files, etc.
• Draw­ing is done accord­ing to the design­er’s habits and needs.
• Tools for full descrip­tions and project details.
• Auto­mat­ic num­ber­ing of objects.
• A sys­tem for quick search of prod­ucts in the database.
• Pos­si­bil­i­ty to fil­ter items, e.g. by dimen­sions or name. Fil­ters can be applied to the whole library mak­ing it much eas­i­er to select dif­fer­ent com­po­nents need­ed to design a giv­en part — for exam­ple, the selec­tion of bolts, wash­ers and nuts with a spe­cif­ic diameter.
• Access to CAD libraries from many world-renowned manufacturers.
• Abil­i­ty to import and add your own sym­bols or objects to the program.
• Auto­mat­ic lay­er man­age­ment and print styles pro­vide the user with prints with pre­de­fined line thick­ness­es, col­ors, etc.
• The abil­i­ty to define ​“favorites” that allow you to work accord­ing to your habits and preferences.
• Com­pres­sion and plate springs.
• Smart inser­tion of objects with the pos­si­bil­i­ty to link them to oth­er objects by using ​“one-click technology”.
• Intel­li­gent com­mands that allow quick edit­ing of sym­bols and objects direct­ly in the drawing.
• The Quick Edit Com­mand (QED) allows the user to per­form basic edit­ing on sym­bols and objects includ­ing edit­ing attrib­ut­es and descrip­tions, mir­ror­ing, scal­ing, copy­ing, rotat­ing, delet­ing, mov­ing and insert­ing alter­nate views.
• The abil­i­ty to cre­ate option­al dia­grams, flow and func­tion charts and algorithms.
• Abil­i­ty to cre­ate bills of mate­ri­als and spec­i­fi­ca­tions that can either be print­ed or export­ed to mul­ti­ple for­mats includ­ing pdf, rtf (doc), xls, xml, csv, html and more.
• Auto­mat­ic cre­ation of graph­i­cal lists.
• Online help with many illus­tra­tions and sam­ple videos describ­ing how to use the pro­gram in detail.
• Online update system.

BIM — Pos­si­bil­i­ty to cre­ate data in BIM tech­nol­o­gy
Build­ing Infor­ma­tion Mod­el­ing (BIM) tech­nol­o­gy is increas­ing­ly used in the con­struc­tion indus­try. Clas­si­fi­ca­tion and man­age­ment of lay­ers based on Open BIM (IFC clas­si­fi­ca­tion) is avail­able in CAD­profi. BIM data is includ­ed in spec­i­fi­ca­tions and can be trans­ferred to pro­grams used dur­ing the invest­ment phase.

In addi­tion, CAD­profi cre­ates data in BIM (includ­ing rfa Revit for­mat) for many man­u­fac­tur­ers. 3D mod­els includ­ed in our pro­gram can also be used in many CAD pro­grams that allow you to import and export files as IFC standard.
