CADprofi Suite

CAD­profi Suite bun­dles all four pro­fes­sion­al mod­ules CAD­profi Archi­tec­tur­al, CAD­profi Elec­tri­cal, CAD­profi HVAC & Pip­ing and CAD­profi Mechan­i­cal into a sin­gle pack­age, offered at a sig­nif­i­cant­ly low­er price.

CA Dprofi Suite

Work faster with the help of four pro­fes­sion­al mod­ules CAD­profi Archi­tec­tur­al, CAD­profi Elec­tri­cal, CAD­profi HVAC & Pip­ing and CAD­profi Mechan­i­cal. CAD­profi Suite brings togeth­er advanced com­mands, the largest library of sym­bols and objects, and many features.

  • When design­ing elec­tri­cal and plumb­ing instal­la­tions, you can first quick­ly draw build­ing plans using the Archi­tec­tur­al module.
  • The rooms defined in the Archi­tec­tur­al mod­ule can be export­ed to the DIALux pro­gram as a fin­ished build­ing plan. After that, light­ing fix­tures select­ed in DIALux can be eas­i­ly import­ed into the Elec­tri­cal mod­ule, after which you can eas­i­ly assign them to the appro­pri­ate elec­tri­cal cir­cuits and cre­ate spec­i­fi­ca­tions. Thanks to this, you can com­plete a com­plete project much faster and easier.
  • In the Archi­tec­tur­al mod­ule, you can spec­i­fy rooms and then use the Arrange com­mand to quick­ly arrange fire detec­tors, sprin­klers and oth­er items from the Elec­tri­cal and HVAC & Pip­ing modules.
  • In the Mechan­i­cal mod­ule, you can design mount­ing meth­ods for tanks, trays, and oth­er items from the Elec­tri­cal and HVAC & Pip­ing modules.
  • In the Elec­tri­cal mod­ule, you can design the elec­tri­cal instal­la­tion for vehi­cle charg­ing sta­tions. Thanks to the Archi­tec­tur­al mod­ule, you can des­ig­nate charg­ing points for cars.
  • You can design evac­u­a­tion and fire pro­tec­tion plans, including:
    • In the Archi­tec­tur­al mod­ule, you can quick­ly draw build­ing plans and cre­ate evac­u­a­tion, fire pro­tec­tion and safe­ty plans.
    • In the Elec­tri­cal mod­ule, you can design fire detec­tion sys­tems, emer­gency light­ing and oth­er intel­li­gent build­ing and secu­ri­ty systems.
    • In the HVAC & Pip­ing mod­ule, you can design all pip­ing and ven­ti­la­tion instal­la­tions, includ­ing fire extin­guish­ing and smoke extrac­tion systems.
  • In the Archi­tec­tur­al mod­ule, you can eas­i­ly define the tech­ni­cal para­me­ters of the rooms (light­ing, ven­ti­la­tion, tem­per­a­ture, heat loss).
  • When cre­at­ing a build­ing plan in the Archi­tec­tur­al mod­ule, you can view the loca­tion of radi­a­tors (e.g. under win­dows or on walls) from the HVAC & Pip­ing module.
  • In the Archi­tec­tur­al mod­ule, you can eas­i­ly insert pen­e­tra­tions (cul­verts) for pipes, ven­ti­la­tion ducts and cable ducts.
